Gedore 2244500 (Series 7UR 21) Combination ratchet spanner, reversible, 21 mm

Description

With same size each end. Ring 13° offset from shaft. UD profile. Working angle 7° from 8 to 15 mm, and 6° from 16 to 24 mm. For ratchet loosening and fast tightening, with lever change. High torque transfer. Hollow profile comfortable to hold. Warp-resistant geometry with double T-girder effect. Gedore vanadium steel 31CrV3. Non-glare look thanks to matt chrome-plating, locking insert and pawl manganese-phosphated. Hot forged. Jaw exactly ground to spanner size. Tried-and-tested Gedore technology combined anew: spanner jaws of classic no. 6, stable hollow shaft of no. 7 and refined mechanism of the U-20 ratchets. In combination with adaptor 7 RA or 7 RB (order separately) the spanner 7 UR can be used as a (bit) ratchet. European Patent applied.

• Length (L, L1):- 274 mm
• Width Across Flat:- 21 mm
• Width of Head (b, b1, n, W3):- 40,0 mm
• Width of Head (b2):- 45,5 mm
• Height of Head (a2):- 6,9 mm
• Angle:- 6 Degree
• Packing Unit:- 5 Piece
• Weight:- 0.264 kg
