Gedore 8011000 (Series 1.29/1) Ball bearing extractor M10x160

Description

For removing ball bearings that are both on a shaft and in a housing. The legs selected using the table are inserted into the ball race, evenly distributed in the outer ring according to the number of balls. The support rings supplied for the ball bearings to be removed are placed on the bearings’ inner races. The head with spindle is then placed on the centering depression of the shaft and the spindle put under tension with the legs. Delivery contains head and spindle. Please order suitable legs separately!.

• Width Across Flat / Actuating Hexagon:- 14 mm
• Diameter of Head:- 28 mm
• Spindle Size (Thread x Length):- M 10 x 160
• Packing Unit:- 1 Piece
• Weight:- 0.2 kg
• Use:- 1.29/10-35
