Gedore 2297213 (Series 7R 27) Combination ratchet spanner 27 mm

Description

With same size each end. Flat pattern. UD profile. Working angle: 7° from 8 to 15 mm, 6° from 16 to 27 mm and 5° from 30 to 36 mm. For ratchet loosening and fast tightening. High torque transfer. Hollow profile comfortable to hold. Warp-resistant geometry with double T-girder effect. Gedore vanadium steel 31CrV3. Non-glare look thanks to matt chrome-plating, locking insert and pawl manganese-phosphated. Hot forged. Jaw exactly ground to spanner size. Tried-and-tested Gedore technology combined anew: spanner jaws of classic no. 6, stable hollow shaft of no. 7 and refined mechanism of the U-20 ratchets. In combination with adaptor 7 RA or 7 RB (please order separately) the spanner 7 R can be used as a (bit) ratchet. European Patent applied.

• Length (L, L1):- 359 mm
• Width Across Flat:- 27 mm
• Width of Head (b, b1, n, W3):- 53,5 mm
• Width of Head (b2):- 59,5 mm
• Height of Head (a, a1, b, h, L2, t):- 14,8 mm
• Height of Head (a2):- 8,3 mm
• Angle:- 6 Degree
• Packing Unit:- 5 Piece
• Weight:- 0.59 kg
